906F

Application:
General Construction, Utilities.

  • 906F
  • 906F
  • Description

  • Specifications

  • Equipped with Yanmar engine, it has strong power,and the industry 's same tonnage industry provideslarge power output and flow, on the basis of ensuringhigh efficiency, it also has higher reliability anddurability.
  • The new main pump displacement is supplied to thesystem on demand, the standby is automaticallyreduced, and the work is provided on demand,reducing energy consumption and energy saving.
  • Air filter, oil filter, diesel filter, antifreeze, lubricationpoint and other main maintenance points arecentralized layout, realizing convenient one-stopmaintenance and inspection.
  • Specifications and designs are subject to changewithout notice.
Operating weight 5,600 kg Engine power 35.9 kW (48 hp/49 ps) @ 2000 rpm
Std. Bucket capacity 0.21 m³ Travel speed(High) 4.1 km/h
Travel speed(Low) 2.5 km/h Maximum swing speed 10.3 rpm
Arm breakout force 31 kN Bucket breakout force 41 kN
Shipping length 5900 mm Shipping width 1960 mm
Track shoe width (std) 400 mm Boom 3000 mm
Arm 1600 mm Digging reach 6185 mm
Digging reach on ground 6050 mm Digging depth 3850 mm
Vertical wall digging depth 3020 mm Cutting height 5700 mm
Dumping height 3950 mm Minimum front swing radius 2430 mm
Dozer-up 360 mm Dozer-down 405 mm
Model Yanmar 4TNV94L-ZCWCLY System maximum flow 136 L/min (36 gal/ min)
System pressure 25 MPa Number of Cylinders 4
